Create without restrictions.
Order now
Unlimited range live streaming & recording over WiFi with the MANUS Bodypack Lite.
Light and compact so it can be worn effortlessly with any motion capture suit. Wirelessly connect your gloves to the built-in dongle for full freedom of movement.
Stream your capture data reliably and swiftly into any of the available integrations, such as Xsens MVN, OptiTrack Motive, Qualisys QTM, Nokov XingYing and Motion Analysis Cortex, or straight into Unreal or Unity through our available plug-ins.
Record your capture data over WiFi in MANUS Core and combine it effortlessly with any body capture solution, such as Vicon Shogun.
Wireless
Wi-Fi 6E (2,4GHz, 5GHz, 6GHz)
Ethernet
1 Gbps
Wireless Gloves
Metagloves Series, Prime 3 Series (requires Prime 3 Wireless Dongle)
Wired Gloves
Metagloves Series, Prime 3 Series
Triggered Recording
Vicon, OptiTrack, Qualisys, Xsens, PeelCapture, Rokoko
Timecode & Sync
Supported, through external device
Power
USB Type-C
Power Input
5V/2.4A
Power Consumption
~2.5W
Battery Life
~7 hours (on 19Wh Power Bank)
Ports
2x USB 2.0 Type-A (for MANUS gloves, MANUS Wireless Dongle)
Management
Wireless over Wi-Fi, Wired over Ethernet, Wired over USB-C
Weight
95 grams (~3½ ounces)
Body Attachment Type
Velcro backed casing, Strap attachment points (strap not included)
Our central software, MANUS Core, is a data-handling tool developed to receive MANUS glove data and output this optimally to your desired target. Using native or added plugins, finger data will stream real-time to Unreal, Unity or MotionBuilder.
Our open SDK allows for building any other integration. The recording function allows you to record your session, edit, and export them as FBX or CSV files.
You will be able to make use of our timecode & genlock feature while recording. On top of that, we have the functionality to trigger your mocap session with the use of our Motive 2.0 triggered recording function and Vicon Shogun triggered recording function. These options allow external software to trigger our recording software and export the recorded data.
