Unlimited range live streaming & recording over WiFi with the MANUS Bodypack Lite.
Light and compact so it can be worn effortlessly with any motion capture suit. Wirelessly connect your gloves to the built-in dongle for full freedom of movement.
Stream your capture data reliably and swiftly into any of the available integrations, such as Xsens MVN, OptiTrack Motive, Qualisys QTM, Nokov XingYing and Motion Analysis Cortex, or straight into Unreal or Unity through our available plug-ins.
Record your capture data over WiFi in MANUS Core and combine it effortlessly with any body capture solution, such as Vicon Shogun.
for improved wearability
at only 95 grams
Robust data quality by eliminating packet loss or dropped frames.
Extendible range through WiFi 6E (2.4GHz, 5GHz and 6GHz available), streaming live to any MANUS integration or plug-in or record and export through MANUS Core.
Connect your MANUS Metagloves wirelessly without additional hardware for a seamless experience.
73% smaller and 60% reduced weight at only 95 grams for a small and lite streaming solution.
Can be applied to any motion capture suit with ease with the velcro backed casing.
No more charging breaks. With its 2.5 Watt power consumption the Bodypack Lite can run for hours on end with a Power Bank.
Wireless
Wi-Fi 6E (2,4GHz, 5GHz, 6GHz)
Ethernet
1 Gbps
Wireless Gloves
Metagloves Series, Prime 3 Series (requires Prime 3 Wireless Dongle)
Wired Gloves
Metagloves Series, Prime 3 Series
Triggered Recording
Vicon, OptiTrack, Qualisys, Xsens, PeelCapture, Rokoko
Timecode & Sync
Supported, through external device
Power
USB Type-C
Power Input
5V/2.4A
Power Consumption
~2.5W
Battery Life
~7 hours (on 19Wh Power Bank)
Ports
2x USB 2.0 Type-A (for MANUS gloves, MANUS Wireless Dongle)
Management
Wireless over Wi-Fi, Wired over Ethernet, Wired over USB-C
Weight
95 grams (~3½ ounces)
Body Attachment Type
Velcro backed casing, Strap attachment points (strap not included)
